How to Build an Agent Trace Analysis Pipeline

When an agent does something wrong, the question is not what the model said; it is what the agent read, what it called, and why it took each step. That record is the trace, and an organization running agents without a trace pipeline is running them blind. This playbook builds the pipeline: capture, storage, and the analyses that turn traces into diagnosis, cost control, and evaluation. It implements the observability model in the AI observability whitepaper and the audit design in how to build an AI audit trail.

Step 1: What must a trace contain?

Element	Content
Identity	Trace identifier; agent identity and version; delegated user; task type
Inputs	Trigger and inputs with trust labels (trusted system data, untrusted content)
Retrieval	Queries, retrieved chunks with sources and scores
Model calls	Prompt version, model and provider, tokens in and out, latency, response
Tool calls	Tool, classification, parameters (redacted), result summary, latency, errors
Approvals	Requested, approver, decision, time
Reasoning	Captured planning or rationale where available
Outputs	Final outputs and end state
Outcome	Success, escalation, failure, with reason

Step 2: Where is capture instrumented?

At the LLM gateway for every model call, at the tool gateway for every action (the MCP gateway), and in the runtime for orchestration and retrieval steps. The runtime issues the trace identifier at task start and propagates it on every call, so the gateways can attach their records. Capturing at the choke points makes traces consistent across frameworks and teams.

Step 3: How are traces stored safely?

Metadata (identities, timings, tokens, tool names, outcomes) and content (prompts, retrieved text, parameters, responses) are stored separately. Content is redacted by data category before storage, retained for a bounded period, and access-controlled more tightly. Credentials and raw delegated tokens are never stored. Retention and access follow the organization's data policy; see AI data privacy compliance.

Step 4: How is failure diagnosis done?

A failed or escalated task's trace is reconstructed step by step to find where behavior diverged from the specification: a misread input, a wrong retrieval, a tool that returned unexpected data, a plan that changed after reading untrusted content, a missing rule. Diagnosis is classified across specification, data, model, tools, and controls, the same taxonomy used in the AI incident postmortem template, so fixes land in the right place.

Step 5: How is cost attributed?

Per trace: tokens by model call, steps, tool calls with unit costs, retrieval cost, and latency, rolled up by task type, agent, and route. This is the data behind cost per completed task and the levers to reduce it, described in the AI agent unit economics whitepaper. Step-count and token anomalies per task are the earliest signal of runaway behavior.

Step 6: How are drift and injection detected?

Drift: track input category mix, retrieval score distributions, step counts, and escalation rates over time; alert on shifts. Injection: flag traces where the plan or tool sequence changed after an untrusted-content read, where a tool call's parameters echo content from a document, or where a prohibited action was attempted; route flagged traces to security review. Detection patterns are described in what is indirect prompt injection.

Step 7: How do traces feed evaluation?

Sampled traces, stratified by category and confidence, go to the human review queue; misses become golden-dataset cases with the trace as rationale; recurring patterns become new categories. The loop is described in how to build a golden dataset.

Step 8: What tooling and views are needed?

A trace viewer that shows a task step by step with trust labels visible; structured queries over metadata (find all traces where tool X errored and the agent retried more than twice); dashboards for cost, steps, escalations, and drift by agent; and links from audit-log entries, approval records, and evaluation results to the trace identifier.

How does the pipeline scale with the fleet?

One agent's traces fit in a log viewer; a fleet's do not. Standardize the trace schema across agents so queries and dashboards are shared, partition storage by agent and date, index metadata for the queries analysts actually run, and sample content retention more aggressively for high-volume, low-risk agents than for consequential ones. Give each agent's owner a view scoped to their agent and give platform, security, and finance cross-fleet views. The registry entry for each agent links to its trace views, so the first place anyone looks for an agent is also where its evidence lives.

What does the pipeline look like in daily use?

An exception handler flags a resolved ticket as wrong; the reviewer opens the trace and sees the agent retrieved a superseded policy page, which is a data finding routed to the knowledge owner and a case for the dataset. The platform dashboard shows one agent's average step count rising over a week; the trace query finds a tool that began returning a new field the agent did not expect, prompting a schema fix. Security's injection monitor flags three traces in which the plan changed after reading a supplier email; two are false positives and one is a real attempt, blocked by the gate and now a golden adversarial case. Finance's cost report attributes the month's spend by task type from the same traces.

What are the common mistakes?

1. Instrumenting per agent instead of at the choke points.
2. Storing raw content without redaction.
3. Traces without trust labels, so injection cannot be detected.
4. No link to approvals and audit, so investigations stall.
5. Traces captured but never analyzed.
6. No owner for the pipeline, so the schema drifts between agents and cross-fleet queries stop working.
